1.(Input Frequency)：
1).Low Band:10.70 GHz -11.70GHz
2).High Band:11.70 GHz -12.75GH
2.(Output Frequency)：
1).Low Band:950-1950MHz
2).High Band:1100-2150MHz
3(L.O. Frequency)：
1).Low Band:9.75GHz(1MHz@25℃)
2).High Band:10.6 GHz(1MHz@25℃)
4(L.O. Stability)：
1).Low Band:±1MHz(-40℃to+70℃)
2).High Band: ±1MHz(-40℃to+70℃)
5(Noise Figure)：0.1 dB
6(Conversion Gain)：≥65dB
7(Gain Flatness)：≤+/-2dB
8(Intput VSWR)：2.5:1(max)
9(Output VSWR)：2.0:1(max)
10(Output Connector):F-female Connector
11(Output Impedance)：75Ω
12(Cross Polar Isolation)：20dB(min)
13(Supply Voltage)：
1)Ca:11.5-14.0v(Vertical Polarization) 13VDCType
2)Cb:16.0-19.0v(Horizontal Polarization)18VDCType
14（Direct Current）：150mA
15(Control Signals)：
1).Low Band:Ca or Cb(see below)
2).High Band:Cc or Cb(see below)
3)Cc:continues 22KHz
16(Operating Temperature)：-40℃to+70℃
17(Storage Temperature)：-40℃to+80℃
18(Relative Humidity)：0%-95%
