Canada NORSAT HS1058A HS1057B HS1057C LNB frequency reducer BAND
model | HS1058A/AF/AN | HS1058B/BF/BN | HS1058C/CF/CN |
frequency range | 11.70-12.20GHz | 12.25-12.75GHz | 10.95-11.70GHz |
Noise coefficient | 0.8dB | 0.8dB | 0.8dB |
Local oscillator frequency stability | 5KHz | 5KHz | 5KHz |
gain | 60dB | 60dB | 60dB |
Local oscillator | 10.75GHz | 11.30GHz | 10.00GHz |
Power supply and power consumption | +15-24V/200mA | +15-24V/200mA | +15-24V/200mA |
Output interface | F/75欧，N/50欧 | F/75欧，N/50欧 | F/75欧，N/50欧 |
weight | 300g | 300g | 300g |
Model classification and meaning of suffix letters for each model:
The HS-1058A or new product model HS-1058AF series is one of the sub models of the same specification products in the HS-1000 high-precision series,
1. For example, HS-1058A or the new model HS-1058AF, which includes a downlink receiving frequency range of 11.70-12.20GHz, a local oscillator frequency of 10.75GHz, a local oscillator stability accuracy error of+/-5KHz, a noise figure of 0.8dB, and a signal output interface of English F-type.
2. For example: HS-1058AN, which refers to the downlink receiving frequency range: 11.70-12.20GHz, local oscillator frequency: 10.75GHz, local oscillator accuracy error: 5KHz, noise coefficient: 0.8dB, signal output interface: N-type.
