Norsat 1008XHB KU-BAND External Reference LNB F or N Type Connector Input 1000XH Series
Norsat's Low Noise Module (LNB) provides signal reception for satellite communications around the world.
Norsat LNB has:
• Input frequencies from 12.25 to 12.75 GHz
0.8dB noise coefficient.
LO stability: phase-locked to external reference
1008XHBF F-type connector
1008XHBN N-type connector
summarize
Norsat satellite communication solutions are renowned for their high quality, reliability, and innovation. Norsat's Low Noise Module (LNB) provides signal reception for satellite communications around the world. Norsat LNB has:
-The industry's best LO (local oscillator) stability
-High performance suitable for any application
-Excellent availability and short delivery time
Inventory units provide standard and extended Ku band frequencies. Special ordering units are available for various additional frequencies ranging from 10.38-10.55 GHz to 17.7-18.1 GHz.
Summary of characteristics:
Noise coefficient 0.8 dB
LO stability phase-locked to external reference
Gain flatness (-40 ° C to+60 ° C) 1.5dBp-p @ over 27 MHz
4dBp-p @ over 500 MHz
Gain variation @ fixed frequency. Max 6 dBp-p
(-40 ° C to+60 ° C)
Phase noise (SSB):
-75 dBc/Hz, 1 kHz
-85 dBc/Hz, 10 kHz
-95 dBc/Hz, 100 kHz
Input VSWR 2.0:1
Output voltage standing wave ratio 2.0: 1
