PBI Turbo-1200 C-Band Dual-Pol CATV LNBF

PBI Turbo-1200 C-Band Dual-Pol CATV LNBF

The PBI Turbo 1200 C-band bipolar single output high-frequency head utilizes the 13/18V voltage in the satellite receiver to receive horizontal or vertical satellite signals. Wide receiving frequency band, low belief noise, high gain, is an indispensable high-quality high-frequency head for C-band household satellite TV reception or using Ku band antennas with efficient feed sources to receive C-band satellite TV signals,

PBI-1200 is a voltage switching dual polarization C-band high-frequency head that utilizes 13/18V different voltages output by satellite TV receivers to LNB to receive satellite TV signals of horizontal or vertical polarization waves. Compared with using mechanical methods to change the polarization direction (such as adjusting polarization with a motor), it has the advantages of a simple feed source structure, convenient installation and debugging, and is equipped with a two ring feed source. It has been tested and certified by a national designated institution. Input frequency 3.4~4.2GHz, output frequency 950~1750MHz, local oscillator frequency 5.15GHz ± 0.5MHz, gain 65dB (type), mirror suppression 50dB (min), output voltage standing wave ratio 2.5:1 (max), output connector 75 Ω, F-type power supply, vertical polarization 12.0~14.5V; Horizontal polarization of 15.0-25.5V when the zero scale is perpendicular to the ground; 200mA (max) cross polarization isolation degree 27dB (type) working temperature -30~60 ℃ volume 180mmx80mmx75mm weight 650g

Equipped with a three ring high-quality thickened pure aluminum feed plate. Pure copper thickened probe, equipped with pure stainless steel screws and waterproof tape.

Features:

Input frequency: 3.4-4.2GHz

Output frequency: 950-1750MHz

Local oscillator frequency: 5.150GHz

Noise coefficient: 17. K

Gain: 65dB

DC power supply: 10-24Vdc/300mA

Working temperature: -40-+60 ℃

Vertical polarization voltage: 10-14.5V

Horizontal polarization voltage: 15.5-20V

The physical picture is as follows: (In stock, the favorite product of barbecue enthusiasts)
