Norsat-KU-1108B LNB KU PLL LNB radio receiver head
Technical indicators
|
Input frequency: 12.25GHz~12.75GHz
Local oscillator frequency: 11.3GHz
Output frequency: 0.95GHz~1.45GHz
Nominal gain: 60dB
Local oscillator stability: ± 5KHz
NF coefficient: 0.6dB
Working voltage: 15-24V
Technical indicators:
Frequency range 10.7-12.75GHz
Output frequency 950~2150MHz
Gain 60Db (type)
Gain flatness ± 0.5dB/27MHz
Local oscillator frequency 9.75/10.6GHz
Local oscillator stability ± 500KHz
Local oscillator phase noise -60dBc/Hz (@ 1KHz)- 80dBc/Hz (@ 10KHz)- 100dBc/Hz (@ 100KHz)
Noise coefficient 0.6dB
Cross isolation degree 27Db (min.)
Parasitic output -60dBc (maximum.)
Output voltage standing wave ratio 2.0:1 (maximum.)
1dB gain compression point output power 0.0dBm (min.)
Mirror suppression 50dB
Polarization mode selection: 11.5V~14.2V vertical polarization; 15.8V~19.0V horizontal polarization (when the zero scale is perpendicular to the ground)
Power supply 10-24V PC, 180mA (maximum.)
Working temperature -30~60 ℃
